THEIA TECHNOLOGIES

Theia Technologies provides high quality megapixel rated lenses for video security and machine vision applications - specializing in ultra wide angle lenses with very minimal optical distortion. Their patented, award-winning Linear Optical Technology® corrects barrel distortion and improves image resolution over typical lenses, while also eliminating the "fisheye" effect. This process allows straight lines to be straight lines in the image. True 4K vari-focal lens models are now offered - including fully motorized versions.

Most models are offered in both C-Mount and CS-Mount models, including both fixed focal and vari-focal length types. Besides 4K models, all others are either 5 megapixel or 3 megapixel rated, with most models having IR correction for day/night cameras. In addition to a full selection of wide angle lens models, a telephoto vari-focal series is offered - targeted towards License Plate Recognition and ITS applications.


4K RESOLUTION (12 MEGAPIXEL RATED) | VARI-FOCAL

1/1.7" FORMAT

TRUE 4K ULTA HD, VARI-FOCAL

MODLE

DESCRIPTION

PDF

SL410A

1/1.7" 4-10mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

SL410P

1/1.7" 4-10mm F1.4 P-Iris Vari-Focal CS-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

SL410M

1/1.7" 4-10mm F1.4 Manual Iris Vari-Focal CS-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

ML410M

1/1.7" 4-10mm F1.4 Manual Iris Vari-Focal C-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

SL1250A

1/1.7" 12-50mm F1.8 DC Auto-Iris Vari-Focal CS-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

SL1250P

1/1.7" 12-50mm F1.8 P-Iris Vari-Focal CS-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

SL1250M

1/1.7" 12-50mm F1.8 Manual Iris Vari-Focal CS-Mount Lens, IR Corrected (Day/Night), 4K Ultra HD, 12 Megapixel Rated

MOTORIZED 4K RESOLUTION (12 MEGAPIXEL RATED) | VARI-FOCAL

1/1.7" FORMAT

TRUE 4K ULTRA HD, VARI-FOCAL - MOTORIZED

MODLE

DESCRIPTION

PDF

TL410A-R3

1/1.7" 4-10mm F1.4 DC Auto-Iris CS-Mount Lens, 4K Ulra HD, 12 Megapixel Rated, Motorized Zoom, Focus & Iris

TL410A-R6

1/1.7" 4-10mm F1.4 DC Auto-Iris CS-Mount Lens, 4K Ultra HD, 12 Megapixel Rated, Motorized Zoom, Focus, Iris & IRC w/limit switch for zoom, focus limits

TL410P-R3

1/1.7" 4-10mm F1.4 P-Iris CS-Mount Lens, 4K Ultra HD, 12 Megapixel Rated, Motorized Zoom, Focus & Iris

TL410P-R6

1/1.7" 4-10mm F1.4 P-Iris CS-Mount Lens, 4K Ultra HD, 12 Megapixel Rated, Motorized Zoom, Focus, Iris & IRC w/limit switch for zoom, focus limits

TL1250A-R3

1/1.7" 12-50mm F1.8 DC Auto-Iris CS-Mount Lens, 4K Ultra HD, 12 Megapixel Rated, Motorized Zoom, Focus & Iris

TL1250A-R6

1/1.7" 12-50mm F1.8 DC Auto-Iris CS-Mount Lens, 4K Ulta HD, 12 Megapixel Rated, Motorized Zoom, Focus, & Iris

TL1250P-R3

1/1.7" 12-50mm F1.8 P-Iris CS-Mount Lens, 4K Ultra HD, 12 Megapixel Rated, Motorized Zoom, Focus & Iris

TL1250P-R6

1/1.7" 12-50mm F1.8 P-Iris CS-Mount Lens, 4K Ultra HD, 12 Megapixel Rated, Motorized Zoom, Focus, Iris & IRC w/limit switch for zoom, focus limits

ULTRA WIDE ANGLE C-MOUNT | MANUAL IRIS & DC AUTO-IRIS

1/2.5" FORMAT

ULTRA WIDE ANGLE (LOW DISTORTION)
5 MEGAPIXEL & 3 MEGAPIXEL RATED C-MOUNT

MODLE

DESCRIPTION

PDF

MY125M

1/2.5" 1.28mm F1.8 Manual Iris C-Mount Lens, 5 Megapixel Rated, IR Sensitivity, <3% Distortion, 135° HFOV (on 1/2.5" Sensor)

MY110M

1/2.5" 1.68mm F1.8 Manual Iris C-Mount Lens, 3 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

MY110A

1/2.5" 1.68mm F1.8 DC Auto-Iris C-Mount Lens, 3 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

ML183M

1/2.5" 1.8-3.0mm F1.8 Manual Iris Vari-Focal C-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

ML183A

1/2.5" 1.8-3.0mm F1.8 DC Auto-Iris Vari-Focal C-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

ULTRA WIDE ANGLE CS-MOUNT | MANUAL IRIS & DC AUTO-IRIS

1/2.5" FORMAT

ULTRA WIDE ANGLE (LOW DISTORTION)
5 MEGAPIXEL & 3 MEGAPIXEL RATED CS-MOUNT

MODLE

DESCRIPTION

PDF

SY125M

1/2.5" 1.28mm F1.8 Manual Iris CS-Mount Lens, 5 Megapixel Rated, IR Sensitivity, <3% Distortion

SY125A

1/2.5" 1.28mm F1.8 DC Auto-Iris CS-Mount Lens, 5 Megapixel Rated, IR Sensitivity, <3% Distortion

SY110M

1/2.5" 1.68mm F1.8 Manual Iris CS-Mount Lens, 3 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

SY110A

1/2.5" 1.68mm F1.8 DC Auto-Iris CS-Mount Lens, 3 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

SL183M

1/2.5" 1.8-3.0mm F1.8 Manual Iris Vari-Focal CS-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

SL183A

1/2.5" 1.8-3.0mm F1.8 DC Auto-Iris Vari-Focal CS-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night), <1% Distortion

TELEPHOTO VARI-FOCAL | CS-MOUNT

1/2.5" FORMAT

TELEPHOTO, 5 MEGAPIXEL RATED CS-MOUNT
(TARGETED FOR LPR & ITS APPLICATIONS)

MODLE

DESCRIPTION

PDF

SL940M

1/2.5" 9-40mm F1.5 Manual Iris Vari-Focal CS-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night)

SL940A

1/2.5" 9-40mm F1.5 DC Auto-Iris Vari-Focal CS-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night)

SL940P

1/2.5" 9-40mm F1.5 P-Iris Vari-Focal CS-Mount Lens, 5 Megapixel Rated, IR Corrected (Day/Night)

`
