SCHNEIDER OPTICS LENSES

Schneider Optics offers superior quality, high resolution C-mount and F-Mount lenses with robust mechanical construction for critical industrial and scientific applications. Most Schneider lenses have been designed with color correction and broadband coating to work well over the entire visible light range from 400-1000nm - and are available in 2/3" format, 1" format, and larger to cover large megapixel camera sensors.

Products include the popular compact series C-Mount (400-1000nm), standard barrel C-Mount (manual and motorized iris), F-Mount, machine vision lens systems, and telecentric lenses, as well as a brand new series of P-Iris type (with stepper motor) for demanding applications for changes in light levels.


XENON-TOPAZ | 1.1" FORMAT C-MOUNT

1.1" FORMAT

12 MEGAPIXEL RATED BROADBAND COATED BETWEEN 400-1000NM

MODLE

DESCRIPTION

PDF

21-1078946

1.1" 30mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

27-1992030

1.1" 30mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated,Ruggedized Version

22-1084646

1.1" 30mm F2.0 Motorized P-Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

21-1076930

1.1" 38mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

27-1992038

1.1" 38mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated, Ruggedized Version

22-1084666

1.1" 38mm F2.0 Motorized P-Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

21-1079220

1.1" 50mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

27-1992050

1.1" 50mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated, Ruggedized Version

27-1084649

1.1" 50mm F2.0 Motorized P-Iris C-Mount Lens, Broadband Coated (400-1000nm), 12 Megapixel Rated

XENON-RUBY | 1/1.8" FORMAT C-MOUNT

1/1.8" FORMAT

OVER 2 MEGAPIXEL RATED
BROADBAND COATED BETWEEN 400-1000NM

MODLE

DESCRIPTION

PDF

21-1074625

1/1.8" 10mm F2.2 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Over 2 Megapixel Rated

21-1074626

1/1.8" 16mm F2.3 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Over 2 Megapixel Rated

21-1068908

1/1.8" 25mm F2.2 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Over 2 Megapixel Rated

21-1074627

1/1.8" 35mm F2.3 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Over 2 Megapixel Rated

XENON-EMERALD | INDUSTRIAL F-MOUNT

43.2MM IMAGE
CIRCLE

VISIBLE CORRECTED
(BROADBAND COATED BETWEEN 400-1000NM)

MODLE

DESCRIPTION

PDF

21-1071609

28mm F2.8 Manual Iris F-Mount Lens, 43.2mm Image Circle, Broadband Coated (400-1000nm), "S" Type (for Short Working Distances)

21-1071606

28mm F2.8 Manual Iris F-Mount Lens, 43.2mm Image Circle, Broadband Coated (400-1000nm), "L" Type (for Long Working Distances)

21-1062672

50mm F2.2 Manual Iris F-Mount Lens, 43.2mm Image Circle, Broadband Coated (400-1000nm)

21-1064881

100mm F2.8 Manual Iris F-Mount Lens, 43.2mm Image Circle, Broadband Coated (400-1000nm), "S" Type (for Short Working Distances)

21-1070506

00mm F2.8 Manual Iris F-Mount Lens, 43.2mm Image Circle, Broadband Coated (400-1000nm), "L" Type (for Long Working Distances)

SWIR TYPE | C-MOUNT

2/3" FORMAT

2/3" FORMAT OPTIMIZED FOR NEAR IR IMAGING, FROM 800NM TO 1800NM WAVELENGTHS

MODLE

DESCRIPTION

PDF

27-1063163

SWIRON 2/3" 23.0mm F1.4 Manual Iris C-Mount Lens, Compact Type, SWIR Type (800-1800nm) for NIR Imaging

5 MEGAPIXEL RATED | VISIBLE CORRRECTED (400-1000NM), C-MOUNT

5 MEGAPIXEL RATED, VISIBLE CORRECTED
(BROADBAND COATED BETWEEN 400-1000NM)

MODLE

DESCRIPTION

PDF

21-1012344

2/3" 23.0mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, Visible Corrected (Broadband Coated Between 400-1000nm), Compact Type, Standard Version

27-1951423

2/3" 23.0mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, Visible Corrected (Broadband Coated Between 400-1000nm), Compact Type, Ruggedized Version

21-1057564

2/3" 35.0mm F1.8 Manual Iris C-Mount Lens, 5 Megapixe Rated, Visible Corrected (Broadband Coated Between 400-1000nm), Compact Type, Standard Version

27-1951835

2/3" 35.0mm F1.8 Manual Iris C-Mount Lens, 5 Megapixel Rated, Visible Corrected (Broadband Coated Between 400-1000nm), Compact Type, Ruggedized Version

COMPACT SERIES | VISIBLE CORRECTED (400-1000NM), C-MOUNT

2/3" FORMAT

COMPACT SERIES - VISIBLE THRU NEAR IR CORRECTED (400-1000NM)

MODLE

DESCRIPTION

PDF

21-1001955

2/3" 4.8mm F1.8 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, Standard Version

21-1055691

2/3" 6mm F2.1 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, Standard Version

21-1001919

2/3" 8.0mm F1.4 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, Standard Version

21-1001951

2/3" 12.0mm F1.4 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, Standard Version

21-1001957

2/3" 17.0mm F1.4 Manual Iris C-Mount Lens, Visible Thru Near IR Corrrected (400-1000nm), Compact Type, Standard Version

21-1001917

2/3" 23.0mm F1.4 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, Standard Version

21-1001960

2/3" 35mm F1.9 Manual Iris C-Mount Lens, Visible Thru Near IR Corrrected (400-1000nm), Compact Type, Standard Version

21-1014593

1" 70mm F2.2 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, Standard Version

COMPACT SERIES | BROADBAND COATED (400-1000NM), C-MOUNT

1" FORMAT

COMPACT SERIES - VISIBLE CORRECTED
(BROADBAND COATED BETWEEN 400-1000NM)

MODLE

DESCRIPTION

PDF

21-1001978

1" 10mm F1.9 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Compact Type, Standard Version

21-1001482

1" 16mm F1.8 Manual Iris C-Mount Lens, Broadband Coated (400-100nm), Compact Type, Standard Version


1.3" FORMAT

COMPACT SERIES - BROADBAND COATED BETWEEN 400-1000NM

MODLE

DESCRIPTION

PDF

21-1001972

1.3" 28.0mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Compact Type, Standard Version

21-1075451

1.3" 35.0mm F2.0 Manual Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Tye, Standard Version

21-1001976

1.3" 50.0mm F2.8 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Compact Type, Standard Version

21-1056472

1.3" 20.0mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Compact Type, Standard Version

21-1071371

1.3" 24.0mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Compact Type, Standard Version

21-1006219

1.3" 35.0mm F2.0 Manual Iris C-Mount Lens, Broadband Coated (400-1000nm), Compact Type, Standard Version

FAST APERTURE | C-MOUNT

2/3" & 1"
FORMAT

C-MOUNT LENSES (VISIBLE) - MANUAL IRIS & FOCUS

MODLE

DESCRIPTION

PDF

21-010456

2/3" 17.0mm F0.95 Manual Iris C-Mount Lens with Lockable Focus and Iris

21-012101

1" 25.0mm F0.95 Manual Iris C-Mount Lens with Lockable Focus and Iris

P-IRIS | MOTORIZED LENSES

2/3" & 1"
FORMAT

P-IRIS MOTORIZED LENSES FOR VARIABLE LIGHT
CONDITIONS - SUCH AS ITS / TRAFFIC CONTROL AND INSPECTION
(WITH CHANGING OBJECT BRIGHTNESS)

MODLE

DESCRIPTION

PDF

22-1061448

2/3" 4.8mm F1.8 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1075636

2/3" 6mm F2.1 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061449

2/3" 8mm F1.4 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061450

2/3" 12mm F1.4 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061451

2/3" 17mm F1.4 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061452

2/3" 23mm F1.4 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061454

2/3" 23mm F1.4 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, 5 Megapixel Rated

22-1061453

2/3" 35mm F1.9 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061455

2/3" 35mm F1.8 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type, 5 Megapixel Rated

22-1061457

2/3" 70mm F2.2 P-Iris C-Mount Lens, Visible Thru Near IR Corrected (400-1000nm), Compact Type

22-1061374

1" 10mm F1.9 P-Iris C-Mount Lens, Broadband Coated Between 400-1000nm, Compact Type

22-1061375

1" 16mm F1.8 P-Iris C-Mount Lens, Broadband Coated Between 400-1000nm, Compact Type

22-1076613

1.3" 24mm F2.0 P-Iris C-Mount Lens, Broadband Coated Between 400-1000nm, Compact Type

22-1061456

1.3" 28mm F2.0 P-Iris C-Mount Lens, Broadband Coated Between 400-1000nm, Compact Type

22-1076612

1.3" 35mm F2.0 P-Iris C-Mount Lens, Broadband Coated Between 400-1000nm, Compact Type

22-1076168

1.3" 50mm F2.8 P-Iris C-Mount Lens, Broadband Coated Between 400-1000nm, Compact Type

LENS ACCESSORIES



MODLE

DESCRIPTION

PDF

21-014604

Schneider Optics Filter Holder/Adapter for Cinegon 4.8mm, 6mm, and 10mm Compact Series Lenses, M62 x 0.75 Filter Size

-
