GOYO LENSES

Goyo Optical Inc. produces lenses used in machine vision and CCTV applications. Lenses include 12 megapixel rated fixed focal lenses, lenses with day/night (IR corrected), 1” and larger formats, auto-iris, fixed focal, and vari-focal types, motorized zoom, and specialty fast aperture F0.95 and 3-CCD models.

Goyo lenses provide exceptional performance and value regardless of format or category. The line includes more individual industrial lens designs than can be found from any other single machine vision lens provider in the world today.


FIXED FOCAL LENGTH | MANUAL IRIS

2/3", 1" & 4/3"
FORMAT

12 MEGAPIXEL RATED HIGH RESOLUTION LENSES

MODLE

DESCRIPTION

PDF

GM12HR39014MCN

2/3" 9mm F1.4 Manual Iris C-Mount Lens, 12 Megapixel Rated, M46 x P0.75 Filter Thread

GM12HR31216MCN

2/3" 12mm F1.6 Manual Iris, C-Mount Lens, 12 Megapixel Rated, M37.7 x P0.75 Filter Thread

GM12HR312514MCN

2/3" 12.5mm F1.4 Manual Iris C-Mount Lens, 12 Megapixel Rated, M46 x P0.75 Filter Thread

GM12HR31814MCN

2/3" 18mm F1.4 Manual Iris C-Mount Lens, 12 Megapixel Rated, M46 x P0.75 Filter Thread

GM12HR41216MCN

1" 12mm F1.6 Manual Iris C-Mount Lens, 12 Megapixel Rated, M52 x P0.75 Filter Thread

GM12HR41616MCN

1" 16mm F1.6 Manual Iris C-Mount Lens, 12 Megapixel Rated, M37.5 x P0.5 Filter Thread

GM12HR42016MCN

1" 20mm F1.6 Manual Iris C-Mount Lens, 12 Megapixel Rated, M39 x P0.5 Filter Thread

GM12HR42516MCN

1" 25mm F1.6 Manual Iris C-Mount Lens, 12 Megapixel Rated, M39 x P0.5 Filter Thread

GM12HR43514MCN

1" 35mm F1.4 Manual Iris C-Mount Lens, 12 Megapixel Rated, M39 x P0.5 Filter Thread

GMHR61220MCN

4/3" 12mm F2.0 Manual Iris C-Mount Lens, Megapixel Rated, M55 x P0.75 Filter Thread

GMHR61620MCN

4/3" 16mm F2.0 Manual Iris C-Mount Lens, Megapixel Rated, M40.5 x P0.5 Filter Thread

GM12HR62520MCN

4/3" 25mm F2.0 Manual Iris C-Mount Lens, 12 Megapixel Rated, M46 x P0.75 Filter Thread

GM12HR63520MCN

4/3" 35mm F2.0 Manual Iris C-Mount Lens, 12 Megapixel Rated, M40.5 x P0.5 Filter Thread

GM12HR65020MCN

4/3" 50mm F2.0 Manual Iris C-Mount Lens, 12 Megapixel Rated, M40.5 x P0.5 Filter Thread


2/3" FORMAT

10 MEGAPIXEL RATED HIGH RESOLUTION LENSES

MODLE

DESCRIPTION

PDF

GM10HR30518MCN

2/3" 5mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.33% Distortion, Broadband Coating (400-900nm)

GM10HR38518MCN

2/3" 8.5mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, 0.31%Distortion, Broadband Coating (400-900nm)

GM10HR31218MCN

2/3" 12.0mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.12% Distortion, Broadband Coating (400-900nm)

GM10HR31618MCN

2/3" 16.0mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.20% Distortion, Broadband Coating (400-900nm)

GM10HR32518MCN

2/3" 25.0mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.09% Distortion, Broadband Coating (400-900nm)

GM10HR33520MCN

2/3" 35.0mm F2.0 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.05% Distortion, Broadband Coating (400-900nm)

GM10HR35028MCN

2/3" 50.0mm F2.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.02% Distortion, Broadband Coating (400-900nm)


2/3" FORMAT

6 MEGAPIXEL RATED HIGH RESOLUTION LENSES

MODLE

DESCRIPTION

PDF

GM6HR38014MCN

2/3" 8mm F1.4 Manual Iris C-Mount Lens, 6 Megapixel Rated

GM6HR31214MCN

2/3" 12mm F1.4 Manual Iris C-Mount Lens, 6 Megapixel Rated

GM6HR31614MCN

2/3" 16mm F1.4 Manual Iris C-Mount Lens, 6 Megapixel Rated

GM6HR32514MCN

2/3" 25mm F1.4 Manual Iris C-Mount Lens, 6 Megapixel Rated


1/1.8" & 2/3"
FORMAT

5 MEGAPIXEL RATED HIGH RESOLUTION LENSES

MODLE

DESCRIPTION

PDF

GMB5HR30528MCN

2/3" 5mm F2.8 Manual Iris C-Mount Lens, 5 Megapixel Rated, M40.5 x P0.5 Filter Thread

GMB5HR38014MCN

2/3" 8mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, M30.5 x P0.5 Filter Thread

GMA5HR31218MCN

2/3" 12mm F1.8 Manual Iris C-Mount Lens, 5 Megapixel Rated, M49 x P0.75 Filter Thread

GMR5HR181214MCN

1/1.8" 12mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, M27 x P0.5 Filter Thread

GMR5HR31614MCN

2/3" 16mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, M27 x P0.5 Filter Thread

GMR5HR32514MCN

2/3" 25mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, M27 x P0.5 Filter Thread

GMR5HR33516MCN

2/3" 35mm F1.6 Manual Iris C-Mount Lens, 5 Megapixel Rated, M27 x P0.5 Filter Thread

GMR5HR35028MCN

2/3" 50mm F2.8 Manual Iris C-Mount Lens, 5 Megapixel Rated, M27 x P0.5 Filter Thread


1/2" & 2/3"
FORMAT

3 MEGAPIXEL RATED WIDE ANGLE LENSES

MODLE

DESCRIPTION

PDF

FE185C046HA-1

1/2" 3.5mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR24514MCN

1/2" 4.5mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR36014MCN

2/3" 6mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated


2/3" FORMAT

3 MEGAPIXEL RATED WITH CLICK-STOP IRIS

MODLE

DESCRIPTION

PDF

GMTHR38014MCN

2/3" 8.25mm F1.44 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR31214MCN

2/3" 12.3mm F1.45 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR31614MCN

2/3" 16.2mm F1.45 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR32514MCN

2/3" 25.0mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR33520MCN

2/3" 35.0mm F2.0 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR35028MCN

2/3" 50.0mm F2.8 Manual Iris C-Mount Lens, 3 Megapixel Rated


1" FORMAT

3 MEGAPIXEL HIGH RESOLUTION LENSES

MODLE

DESCRIPTION

PDF

GMTHR48014MCN

1" 8mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR412514MCN

1" 12.5mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR41614MCN

1" 16mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR42514MCN

1" 25mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR43514MCN

1" 35mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated

GMTHR45014MCN

1" 50mm F1.4 Manual Iris C-Mount Lens, 3 Megapixel Rated


1" & 2/3"
FORMAT

F0.95 HIGH SPEED LENSES

MODLE

DESCRIPTION

PDF

GMY31795MCN

2/3" 17mm F0.95 Manual Iris C-Mount Lens, M40.5 x P0.5 Filter Thread

GMY42595MCN

1" 25mm F0.95 Manual Iris C-Mount Lens, M40.5 x P0.5 Filter Thread

GMV42595MC

1" 25mm F0.95 Manual Iris C-Mount Lens, M40.5 x P0.5 Filter Thread

GMY45095MCN

1" 50mm F0.95 Manual Iris C-Mount Lens, M62 x P0.75 Filter Thread

FISH EYE TYPE | INDUSTRIAL LENS

1/4" & 2/3"
FORMAT

MODLE

DESCRIPTION

PDF

GM5HR31814MCN

2/3" 1.8mm (Fisheye) F1.4 Manual Iris with Fixed Focus C-Mount Lens, 5 Megapixel Rated, 185° FOV

GM5HR318161MCN

2/3" 1.8mm (Fisheye) F1.61 Fixed Iris C-Mount Lens, 5 Megapixel Rated, 185° FOV

GM141228M12

1/4" 1.2mm (Fisheye) F2.8 Fixed Focus & Iris M12 Mount Lens, 192° FOV

FIXED FOCAL LENGTH | 29 MEGAPIXEL RATED F-MOUNT

Ø44MM IMAGE
CIRCLE

MODLE

DESCRIPTION

PDF

GLSW2528F

25mm F2.8 Manual Iris F-Mount Lens, 44mm Image Circle, 29 Megapixel Rated

GLSW3528F

35mm F2.8 Manual Iris F-Mount Lens, 44mm Image Circle, 29 Megapixel Rated

GLSW5028F

50mm F2.8 Manual Iris F-Mount Lens, 44mm Image Circle, 29 Megapixel Rated

GLSW10028F

100mm F2.8 Manual Iris F-Mount Lens, 44mm Image Circle, 29 Megapixel Rated

TF25DA-8B

1/3" 25mm F2.2 Manual Iris C-Mount Lens, 3-CCD Type

FIXED FOCAL LENGTH | VIDEO AUTO IRIS

1" FORMAT

MODLE

DESCRIPTION

PDF

GA42514AC

1" 25mm F1.4 Video Auto-Iris C-Mount Lens

GA45018AC

1" 50mm F1.8 Video Auto-Iris C-Mount Lens

GA47518AC

1" 75mm F1.8 Video Auto-Iris C-Mount Lens

FIXED FOCAL LENGTH | DC AUTO IRIS

1" FORMAT

MODLE

DESCRIPTION

PDF

GA42514BC4

1" 25mm F1.4 DC Auto-Iris C-Mount Lens

GA45018BC4

1" 50mm F1.8 DC Auto-Iris C-Mount Lens

GA47518BC4

1" 75mm F1.8 DC Auto-Iris C-Mount Lens
