KOWA LENSES

Kowa Optimed, Inc. offers CCTV lenses for FA industrial, machine vision, and video security. These include megapixel/HD lenses with low distortion, a ruggedized megapixel lens series, IR vari-focals, P-Iris (remote motorized iris), telecentric type and motorized zoom lenses (up to 5-megapixel rated), and out to 1000mm true optical telephoto range (no internal extender).

For high-end machine vision and industrial automation, a 10 megapixel C-Mount series, 4/3" format C-Mount series (8 megapixel rated), linescan lenses with (Nikon) F-Mount, and M48 Mount models are available. Also offered is a series of 1" format megapixel rated SWIR lenses - for transmission in the 800-2000nm range. NF-Mount megapixel rated series lenses are also available.


LARGE FORMAT LENSES | 1" FORMAT AND LARGER

1.3" (4/3")
FORMAT

LOW DISTORTION W/ WIDE BAND COATING
(RATED TO OVER 8-MEGAPIXELS)
MAXIMUM SENSOR COVERAGE:
23MM (D), 18.4MM (H), 13.8MM (V)

MODLE

DESCRIPTION

PDF

LM8XC

4/3" 8.5mm F2.8 Manual Iris C-Mount Lens (Over 8-megapixel Rated)

LM12XC

4/3" 12mm F2.0 Manual Iris C-Mount Lens (Over 8-megapixel Rated)

LM16XC

4/3" 16mm F2.0 Manual Iris C-Mount Lens (Over 8-megapixel Rated)

LM25XC

4/3" 25mm F2.0 Manual Iris C-Mount Lens (Over 8-megapixel Rated)

LM35XC

4/3" 35mm F2.0 Manual Iris C-Mount Lens (Over 8-megapixel Rated)

LM50XC

4/3" 50mm F2.0 Manual Iris C-Mount Lens (Over 8-megapixel Rated)


1" FORMAT

SWIR TYPE (800-2000NM), MEGAPIXEL RATED
(FOR NEAR INFRARED & SHORT WAVELENGTH
INFRARED APPLICATIONS)

MODLE

DESCRIPTION

PDF

LM8HC-SW

1" 8mm F1.4 Manual Iris C-Mount Lens, SWIR Type (800-2000nm), Megapixel Rated

LM12HC-SW

12.5mm F1.4 Manual Iris C-Mount Lens, SWIR Type (800-2000nm), Megapixel Rated

LM16HC-SW

1" 16mm F1.4 Manual Iris C-Mount Lens, SWIR Type (800-2000nm), Megapixel Rated

LM25HC-SW

1" 25mm F1.4 Manual Iris C-Mount Lens, SWIR Type (800-2000nm), Megapixel Rated

LM50HC-SW

1" 50mm F1.4 Manual Iris C-Mount Lens, SWIR Type (800-2000nm), Megapixel Rated


46MM IMAGE
CIRCLE

MEGAPIXEL RATED, LARGE FORMAT, DESIGNED FOR 4K LINE SCAN CAMERAS

MODLE

DESCRIPTION

PDF

LM28LF

28mm F2.8 Manual Iris (Nikon) F-Mount Lens, 46mm Image Circle

LM35LF

35mm F2.8 Manual Iris (Nikon) F-Mount Lens, 46mm Image Circle

LM50LF

50mm F2.8 Manual Iris (Nikon) F-Mount Lens, 46mm Image Circle


30MM SENSOR
SIZE

3-CCD COLOR LINE SCAN, MEGAPIXEL RATED, F-MOUNT

MODLE

DESCRIPTION

PDF

LM28CLS

28mm F2.8 Manual Iris (Nikon) F-Mount Lens (Mega Pixel), For 3-CCD Line Scan Cameras

LM35CLS

35mm F2.8 Manual Iris (Nikon) F-Mount Lens (Mega Pixel), For 3-CCD Line Scan Cameras

LM50CLS

50mm F1.4 Manual Iris (Nikon) F-Mount Lens (Mega Pixel), For 3-CCD Line Scan Cameras


43.3MM IMAGE
CIRCLE

MEGAPIXEL RATED, LARGE FORMAT

MODLE

DESCRIPTION

PDF

LM50-IR-F

50.0mm F1.9 Manual Iris F-Mount Lens w/ Broadband Coating (400-1000nm), IR Sensitivity, Low Distortion, 43.3mm Image Circle

LM50-IR-P

50.0mm F1.9 Manual Iris P-Mount (M42 Mount) Lens w/ Broadband Coating (400-1000nm), IR Sensitivitiy, Low Distortion, 43.3mm Image Circle

SC SERIES | 1" 6 MEGAPIXEL RATED

1" FORMAT

6 MEGAPIXEL RATED FOR MACHINE VISION
(DESIGNED FOR CAMERA SENSORS DOWN TO 3.5
MICRONS PIXEL SIZE)

MODLE

DESCRIPTION

PDF

LM12SC

1" 12mm F1.8 Manual Iris C-Mount Lens, 6 Megapixel Rated

LM16SC

1" 16mm F1.8 Manual Iris C-Mount Lens, 6 Megapixel Rated

LM25SC

1" 25mm F1.8 Manual Iris C-Mount Lens, 6 Megapixel Rated

LM35SC

1" 35mm F2.0 Manual Iris C-Mount Lens, 6 Megapixel Rated

LM50SC

1" 50mm F2.0 Manual Iris C-Mount Lens, 6 Megapixel Rated

HC-V SERIES | RUGGEDIZED 1" MEGAPIXEL RATED

1" FORMAT

RUGGEDIZED ANTI-VIBRATION & HIGH SHOCK
LENSES,
2 MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM8HC-V

1" 8mm F1.4/F2.8/F4/F8 Fixed Iris C-Mount Lens, 2 Megapixel Rated, Ruggedized

LM12HC-V

1" 12.5mm F1.4/F2.8/F4/F8 Fixed Iris C-Mount Lens, 2 Megapixel Rated, Ruggedized

LM16HC-V

1" 16mm F1.4/F2.8/F4/F8 Fixed Iris C-Mount Lens, 2 Megapixel Rated, Ruggedized

LM25HC-V

1" 25mm F1.4/F2.8/F4/F8 Fixed Iris C-Mount Lens, 2 Megapixel Rated, Ruggedized

LM35HC-V

1" 35mm F1.4/F2.8/F4/F8 Fixed Iris C-Mount Lens, 2 Megapixel Rated, Ruggedized

LM50HC-V

1" 50mm F1.4/F2.8/F4/F8 Fixed Iris C-Mount Lens, 2 Megapixel Rated, Ruggedized

HC SERIES | 1" 2 MEGAPIXEL RATED

1" FORMAT

HIGH RESOLUTION FIXED LENSES - 2 MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM6HC

1" 6.0mm F1.8 Manual Iris C-Mount Lens, 2 Megapixel Rated

GMY42595MCN

1" 8.0mm F1.4 Manual Iris C-Mount Lens, 2 Megapixel Rated

LM12HC

1" 12.5mm F1.4 Manual Iris C-Mount Lens, 2 Megapixel Rated

LM16HC

1" 16.0mm F1.4 Manual Iris C-Mount Lens, 2 Megapixel Rated

LM25HC

1" 25.0mm F1.4 Manual Iris C-Mount Lens, 2 Megapixel Rated

LM35HC

1" 35.0mm F1.4 Manual Iris C-Mount Lens, 2 Megapixel Rated

LM50HC

1" 50.0mm F1.4 Manual Iris C-Mount Lens, 2 Megapixel Rated

LM75HC

1" 75.0mm F1.8 Manual Iris C-Mount Lens, 2 Megapixel Rated

LMVZ166HC

1" 16-64mm F1.8 Manual Iris Vari-Focal C-Mount Lens, 2 Megapixel Rated

JC10M SERIES | 2/3" 10 MEGAPIXEL RATED

2/3" FORMAT

10-MEGAPIXEL, LOW DISTORTION FIXED LENSES
(200 LP/MM RESOLUTION IN CENTER;
BROADBAND COATING WITH 400-900NM
RANGE)

MODLE

DESCRIPTION

PDF

LM5JC10M

2/3" 5mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.33% Distortion, Broadband Coating (400-900nm)

LM8JC10M

2/3" 8.5mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, 0.31%Distortion, Broadband Coating (400-900nm)

LM12JC10M

2/3" 12.0mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.12% Distortion, Broadband Coating (400-900nm)

LM16JC10M

2/3" 16.0mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.20% Distortion, Broadband Coating (400-900nm)

LM25JC10M

2/3" 25.0mm F1.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.09% Distortion, Broadband Coating (400-900nm)

LM35JC10M

2/3" 35.0mm F2.0 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.05% Distortion, Broadband Coating (400-900nm)

LM50JC10M

2/3" 50.0mm F2.8 Manual Iris C-Mount Lens, 10 Megapixel Rated, -0.02% Distortion, Broadband Coating (400-900nm)

JC5M2 SERIES | 2/3" 5 MEGAPIXEL RATED

2/3" FORMAT

5-MEGAPIXEL RATED WITH ROBUST MECHANICAL DESIGN

MODLE

DESCRIPTION

PDF

LM12JC5M2

2/3" 12mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

LM16JC5M2

2/3" 16mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

LM25JC5M2

2/3" 25mm F1.6 Manual Iris C-Mount Lens, 5 Megapixel Rated

LM35JC5M2

2/3" 35mm F1.6 Manual Iris C-Mount Lens, 5 Megapixel Rated

JCM-V SERIES | RUGGEDIZED 2/3" 2 MEGAPIXEL RATED

2/3" FORMAT

RUGGEDIZED ANTI-VIBRATION & HIGH SHOCK
LENSES,
2 MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM8JCM-V

2/3" 8.0mm F1.4/F4/F8/F16 Fixed Iris C-Mount Lens, 2-Megapixel Rated, Ruggedized

LM12JCM-V

2/3" 12.0mm F1.4/F4/F8/F16 Fixed Iris C-Mount Lens, 2-Megapixel Rated, Ruggedized

LM16JCM-V

2/3" 16.0mm F1.4/F4/F8/F16 Fixed Fixed C-Mount Lens, 2-Megapixel Rated, Ruggedized

LM25JCM-V

2/3" 25.0mm F1.4/F4/F8/F16 Fixed Iris C-Mount Lens, 2-Megapixel Rated, Ruggedized

LM35JCM-V

2/3" 35.0mm F2.0/F4/F8/F16 Fixed Iris C-Mount Lens, 2-Megapixel Rated, Ruggedized

LM50JCM-V

2/3" 50.0mm F2.8/F4/F8/F16 Fixed Iris C-Mount Lens, 2-Megapixel Rated, Ruggedized

JCM SERIES | 2/3" 2 MEGAPIXEL RATED

2/3" FORMAT

2-MEGAPIXEL, LOW DISTORTION FIXED LENSES

MODLE

DESCRIPTION

PDF

LM5JCM

2/3" 5.0mm F2.8 Manual Iris C-Mount Lens, 2-Megapixel Rated

LM8JCM

2/3" 8.0mm F1.4 Manual Iris C-Mount Lens, 2-Megapixel Rated

LM12JCM

2/3" 12.0mm F1.4 Manual Iris C-Mount Lens, 2-Megapixel Rated

LM16JCM

2/3" 16.0mm F1.4 Manual Iris C-Mount Lens, 2-Megapixel Rated

LM25JCM

2/3" 25.0mm F1.4 Manual Iris C-Mount Lens, 2-Megapixel Rated

LM35JCM

2/3" 35.0mm F2.0 Manual Iris C-Mount Lens, 2-Megapixel Rated

LM50JCM

2/3" 50.0mm F2.8 Manual Iris C-Mount Lens, 2-Megapixel Rated

JC SERIES | 2/3" HIGH RESOLUTION

2/3" FORMAT

HIGH RESOLUTION FIXED LENSES, FA INDUSTRIAL

MODLE

DESCRIPTION

PDF

LM6JC

2/3" 6.0mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM8JC

2/3" 8.0mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM12JC

2/3" 12.0mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM16JC

2/3" 16.0mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM25JC

2/3" 25.0mm F1.6 Manual Iris C-Mount Lens w/ Locking Screws

LM35JC

2/3" 35.0mm F1.6 Manual Iris C-Mount Lens w/ Locking Screws

LM50JC

2/3" 50.0mm F2.0 Manual Iris C-Mount Lens w/ Locking Screws

LM75JC

2/3" 75.0mm F2.5 Manual Iris C-Mount Lens w/ Locking Screws

LM100JC

2/3" 100.0mm F2.8 Manual Iris C-Mount Lens w/ Locking Screws

NCL SERIES | 1/2" HIGH RESOLUTION RATED

1/2" FORMAT

HIGH RESOLUTION FIXED LENSES, FA INDUSTRIAL

MODLE

DESCRIPTION

PDF

LM4NCL

1/2" 3.5mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM5NCL

1/2" 4.5mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM6NCL

1/2" 6.0mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

LM12NCL

1/2" 12.0mm F1.4 Manual Iris C-Mount Lens w/ Locking Screws

NCM SERIES | 1/1.8" & 1/2" 2 MEGAPIXEL RATED

1/1.8" & 1/2"
FORMAT

2 MEGAPIXEL, LOW DISTORTION FIXED LENSES

MODLE

DESCRIPTION

PDF

LM3NCM

1/1.8" 3.5mm F2.4 Manual Iris C-Mount Lens w/ Locking Screws, 2-Megapixel Rated

LM4NCM

1/1.8" 4.4mm F1.6 Manual Iris C-Mount Lens w/ Locking Screws, 2-Megapixel Rated

LM6NCM

1/2" 6.0mm F1.2 Manual Iris C-Mount Lens w/ Locking Screws, 2-Megapixel Rated

NC3 SERIES | 1/2" 3-CCD TYPE, MEGAPIXEL RATED

1/2" FORMAT

3-CCD TYPE, MEGAPIXEL

MODLE

DESCRIPTION

PDF

LM4NC3

1/2" 4mm F1.8 Manual Iris C-Mount Lens w/ Locking Screws for 3-CCD Camera, Megapixel Rated

LM6NC3

1/2" 6mm F1.8 Manual Iris C-Mount Lens w/ Locking Screws for 3-CCD Camera, Megapixel Rated

LM12NC3

1/2" 12mm F1.8 Manual Iris C-Mount Lens w/ Locking Screws for 3-CCD Camera, Megapixel Rated

LM25NC3

1/2" 25mm F1.8 Manual Iris C-Mount Lens w/ Locking Screws for 3-CCD Camera, Megapixel Rated

LM50NC3

1/2" 50mm F1.8 Manual Iris C-Mount Lens w/ Locking Screws for 3-CCD Camera, Megapixel Rated

TELECENTRIC TYPE LENSES | MEGAPIXEL RATED

4/3" & 2/3"
FORMAT

TELECENTRIC TYPE - MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM1119TC

4/3" 0.5X-1.0X Magnification, Manual Iris Telecentric Type Macro C-Mount Lens, 21 Megapixel Rated

LM1138TC

4/3" 2.0X Magnification, Manual Iris Telecentric Type Macro C-Mount Lens, 21 Megapixel Rated

LM1120TC

2/3" 3.45-4.4X Magnification, Manual Iris Telecentric Type Macro Zoom Lens, Over 5 Megapixel Rated

LM1122TC

2/3" 1.15X-1.47X Magnification, Manual Iris Telecentric Type Macro Zoom C-Mount Lens, Over 5 Megapixel Rated

LM1123TC

2/3" 0.69X-0.88X Magnification, Manual Iris Telecentric Type Macro Zoom C-Mount Lens, Over 5 Megapixel Rated

LM1125TC

2/3" 0.346-0.44X Magnification, Manual Iris Telecentric Type Macro Zoom C-Mount Lens, Over 5 Megapixel Rated

LM50TC

2/3" 50.0mm F2.8 Manual Iris Telecentric Type C-Mount Lens w/ Locking Screws, Focus Range 0.085m to Infinity, Megapixel Rated


1/3" & 2/3"
FORMAT

MANUAL ZOOM, FOCUS & IRIS WITH MACRO

MODLE

DESCRIPTION

PDF

LMZ45T3

2/3" 18.0-108.0mm F2.5 Manual Zoom, Focus & Iris C-Mount Lens w/ Locking Screws (Macro), Focus Range 130mm to Infinity

LMZ50M

1/3" 8.5-90.0mm F2.5 Manual Zoom, Focus & Iris C-Mount Lens w/ Locking Screws (Macro)

FIXED FOCAL LENSES | MANUAL IRIS

1/2" FORMAT

RECOMMENDED FOR CAMERAS UP TO 1 MEGAPIXEL RESOLUTION

MODLE

DESCRIPTION

PDF

LM4NCL

1/2" 3.5mm F1.4 Manual Iris C-Mount Lens

LM5NCR

1/2" 4.5mm F1.4 Manual Iris C-Mount Lens

LM6NCR

1/2" 6.0mm F1.4 Manual Iris C-Mount Lens

LM12NCR

1/2" 12.0mm F1.4 Manual Iris C-Mount Lens

NF SERIES | 1/3" NF-MOUNT MEGAPIXEL RATED

1/3" FORMAT

NF MOUNT, MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM3NF

1/3" 2.7mm F1.8 Manual Iris NF-Mount Lens, Megapixel

LM5NF

1/3" 4.5mm F1.8 Manual Iris NF-Mount Lens, Megapixel

LM9NF

1/3" 9mm F1.8 Manual Iris NF-Mount Lens, Megapixel

FIXED FOCAL | P-IRIS 5 MEGAPIXEL RATED

2/3" FORMAT

SPECIALLY DESIGNED FOR P-IRIS DIGITAL
CAMERAS,
5-MEGAPIXEL RATED, DAY/NIGHT

MODLE

DESCRIPTION

PDF

LM16JC5MM-IR

2/3" 16mm F1.4 P-Iris C-Mount Lens, 5-Megapixel Rated, IR Corrected, Day/Night

LM25JC5MM-IR

2/3" 25mm F1.4 P-Iris C-Mount Lens, 5-Megapixel Rated, IR Corrected, Day/Night

LM35JC5MM-IR

2/3" 35mm F2.0 P-Iris C-Mount Lens, 5-Megapixel Rated, IR Corrected, Day/Night

DC AUTO-IRIS | 5 MEGAPIXEL RATED

1" FORMAT

HIGH SPEED DC AUTO-IRIS LENSES, 5 MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM25JS5MA

1" 25mm F0.85 DC Auto-Iris CS-Mount Lens, 5 Megapixel Rated

LM35JS5MA

1" 35mm F0.85 DC Auto-Iris CS-Mount Lens, 5 Megapixel Rated

LM60JS5MA

1" 60mm F0.8 DC Auto-Iris CS-Mount Lens, 5 Megapixel Rated

DC AUTO-IRIS | 5 MEGAPIXEL RATED

2/3" FORMAT

DC AUTO-IRIS LENSES WITH DAY/NIGHT (IR CORRECTED), 5 MEGAPIXEL RATED

MODLE

DESCRIPTION

PDF

LM16JC5MA-IR

2/3" 16mm F1.4 DC Auto-Iris C-Mount Lens, 5 Megapixel Rated, Day & Night, IR Corrected

LM25JC5MA-IR

2/3" 25mm F1.4 DC Auto-Iris C-Mount Lens, 5 Megapixel Rated, Day & Night, IR Corrected

LM35JC5MA-IR

2/3" 35mm F2.0 DC Auto-Iris C-Mount Lens, 5 Megapixel Rated, Day & Night, IR Corrected

FIXED FOCAL | DC AUTO IRIS

1/3" FORMAT

RECOMMENDED FOR CAMERAS UP TO 1 MEGAPIXEL RESOLUTION

MODLE

DESCRIPTION

PDF

LM2.3PB

1/3" 2.3mm F1.4 DC Auto-Iris CS-Mount Lens

LM3PB

1/3" 2.8mm F1.4 DC Auto-Iris CS-Mount Lens

VARI-FOCAL | MANUAL IRIS

1/1.8" FORMAT

MEGAPIXEL/HD LENS

MODLE

DESCRIPTION

PDF

LMVZ4411

1/1.8" 4.4-11.0mm F1.6 Manual Iris Vari-Focal C-Mount Lens, Megapixel

LMVZ1040

1/1.8" 10.0-40.0mm F1.6 Manual Iris Vari-Focal C-Mount Lens, Megapixel


1/2" FORMAT

FOR MEGAPIXEL AND STANDARD RESOLUTION CAMERAS

MODLE

DESCRIPTION

PDF

LMVZ41

1/2"4.0-10.0mm F1.8 Manual Iris Vari-Focal CS-Mount Lens

LMVZ655

1/2" 6.5-52.0mm F1.8 Manual Iris Vari-Focal C-Mount Lens

LMVZ9020-IR

1/2" 9.0-20.0mm F1.6 Manual Iris Vari-Focal CS-Mount Lens, IR, Megapixel

LMVZ990-IR

1/2" 9.0-90.0mm F1.8 Manual Iris Vari-Focal C-Mount Lens, IR


1/3" FORMAT

RECOMMENDED FOR CAMERAS UP TO 1 MEGAPIXEL RESOLUTION

MODLE

DESCRIPTION

PDF

LMVZ164

1/3" 1.6-3.4mm F1.4 Manual Iris Vari-Focal CS-Mount Lens

LMVZ256

1/3" 2.5-6.0mm F1.4 Manual Iris Vari-Focal CS-Mount Lens

LMVZ282-HR

1/3" 2.8-12.0mm F1.4 Manual Iris Vari-Focal CS-Mount Lens

LMVZ540

1/3" 5.0-40.0mm F1.6 Manual Iris Vari-Focal CS-Mount Lens

LMVZ580

1/3" 5.5-82.5mm F1.8 Manual Iris Vari-Focal CS-Mount Lens

VARI-FOCAL | P-IRIS

1/2" FORMAT

SPECIFICALLY DESIGNED FOR P-IRIS CAMERAS

MODLE

DESCRIPTION

PDF

LMVZ3510M-IR

1/2" 3.5-10.0mm F1.6 P-Iris CS-Mount Lens, IR, Megapixel

LMVZ41M

1/2" 4-10.0mm F1.8 P-Iris CS-Mount Lens, High Resolution

LMVZ9020M-IR

1/2" 9.0-20.0mm F1.6 P-Iris CS-Mount Lens, IR, Megapixel

VARI-FOCAL | DC AUTO IRIS

1/2" FORMAT

FOR MEGAPIXEL AND STANDARD RESOLUTION CAMERAS

MODLE

DESCRIPTION

PDF

LMVZ41A

1/2" 4.0-10.0mm F1.8 DC Auto-Iris Vari-Focal CS-Mount Lens

LMVZ655A

1/2" 6.5-52.0mm F1.8 DC Auto-Iris Vari-Focal C-Mount Lens

LMVZ9020A-IR

1/2" 9.0-20.0mm F1.6 DC Auto-Iris Vari-Focal CS-Mount Lens, IR, Megapixel

LMVZ990A-IR

1/2" 9.0-90.0mm F1.8 DC Auto-Iris Vari-Focal C-Mount Lens, IR


1/3" FORMAT

RECOMMENDED FOR CAMERAS UP TO 1 MEGAPIXEL RESOLUTION

MODLE

DESCRIPTION

PDF

LMVZ164A

1/3" 1.6-3.4mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens

LMVZ256A

1/3" 2.5-6.0mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens

LMVZ272A

1/3" 2.7-12.0mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens

LMVZ38A-IR

1/3" 3.0-8.0 F1.0 DC Auto-Iris Vari-Focal CS-Mount Lens, IR

LMVZ282A-IR

1/3" 2.8-12.0mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens, IR

LMVZ282A-HR

1/3" 2.8-12.0mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens, High Resolution

LMVZ540A

1/3" 5.0-40.0mm F1.6 DC Auto-Iris Vari-Focal CS-Mount Lens

LMVZ550A-IR

1/3" 5.0-50.0mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens, IR

LMVZ580A

1/3" 5.5-82.5mm F1.8 DC Auto-Iris Vari-Focal CS-Mount Lens

LMVZ510A

1/3" 5.0-100.0mm F1.6 DC Auto-Iris Vari-Focal CS-Mount Lens

MANUAL ZOOM | MANUAL IRIS

1/3", 1/2" & 2/3"
FORMAT

MANUAL ZOOM, FOCUS & IRIS C-MOUNT LENS

MODLE

DESCRIPTION

PDF

LMZ45T3

2/3" 18.0-108.0mm F2.5 Manual Zoom, Focus & Iris C-Mount Lens (with Macro)

LMZ69M

2/3" 11.5-69.0mm F1.4 Manual Zoom, Focus & Iris C-Mount Lens (with Macro)

LMZ68M

1/2" 8.0-48mm F1.0 Manual Zoom, Focus & Iris C-Mount (with Macro)

LMZ50M-C

1/3" 8.5-90.0mm F2.5 Manual Zoom, Focus & Iris C-Mount (with Macro)

MOTORIZED ZOOM | SWIR TYPE

MEGAPIXEL SWIR ZOOM LENS SERIES

MODLE

DESCRIPTION

PDF

LMZ16160M3P-SW

1" 16.0-160.0mm F1.9 Motorized Zoom, Focus & Iris (3 Motor) C-Mount Lens, Presets (Zoom & Focus), 5 Megapixel Rated, SWIR Type

LMZ1177M3P-SW

2/3" 11.0-77.0mm F1.6 Motorized Zoom, Focus & Iris (3 Motor) C-Mount Lens, Presets (Zoom & Focus), 5 Megapixel Rated, SWIR

LMZ25300M3P-SW

1" 25.0-300.0mm F2.8 Motorized Zoom, Focus & Iris (3 Motor) C-Mount Lens, Presets (Zoom & Focus), 5 Megapixel Rated, SWIR Type

LMZ20750AMPDC-SW

1/1.8" 20.0-750.0mm F4.6 Motorized Zoom & Focus with DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Megapixel Rated, SWIR Type

MOTORIZED ZOOM | DC AUTO IRIS

1/2" FORMAT

MOTORIZED ZOOM & FOCUS, DC AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ0812AMDC-IR

1/2" 8.0-120.0mm F1.8 Motorized Zoom & Focus DC Auto-Iris C-Mount Lens, Megapixel, IR

LMZ7527AMDC

1/2" 7.5-127.0mm F1.6 Motorized Zoom & Focus DC Auto-Iris C-Mount Lens, Megapixel

LMZ112AMDC

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus DC Auto-Iris C-Mount Lens

LMZ123AMDC

1/2" 12.0-300.0mm F1.8 Motorized Zoom & Focus DC Auto-Iris C-Mount Lens

LMZ375AMDC

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus DC Auto-Iris C-Mount Lens, XD Lens, IR

LMZ750AMDC

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus DC Auto-Iris C-Mount Lens, XD Lens, IR


1/3" FORMAT

MOTORIZED ZOOM & FOCUS, DC AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ111AMDC

1/3" 6.0-60.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens

LMZ110AMDC

1/3" 6.0-90.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens

LMZ200AMDC

1/3" 5.6-112.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens

LMZ300AMDC

1/3" 5.5-165.0mm F1.8 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens

MOTORIZED ZOOM | VIDEO AUTO IRIS

1/2" FORMAT

MOTORIZED ZOOM & FOCUS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ0812AM-IR

1/2" 8.0-120.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Megapixel, IR

LMZ7527AM

1/2" 7.5-127.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Megapixel

LMZ112AM

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens

LMZ123AM

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount, Extended IR Sensitivity

LMZ750AM-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount, Extended IR Sensitivity


1/3" FORMAT

MOTORIZED ZOOM & FOCUS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ111AM

1/3" 6.0-60.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens

LMZ110AM

1/3" 6.0-90.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens

LMZ200AM

1/3" 5.6-112.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens

LMZ300AM

1/3" 5.5-165.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens

MOTORIZED ZOOM | DC AUTO IRIS

1" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, DC AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ16160AMPDC-IR

1" 16-160mm F1.9 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, IR Corrected, Presets, XD Glass (eXtra low Dispersion), 5-Megapixel Rated

LMZ25300AMPDC-IR

1" 25-300mm F2.8 Motorized Zoom & Focus with DC Auto-Iris C-Mount Lens, IR Corrected, Presets (Zoom & Focus), 5 Megapixel Rated


1/1.8" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, DC AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ0824AMPDC-XF

1/1.8" 8.0-240.0mm F1.7 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity, Megapixel Rated

LMZ1236AMPDC-XF

1/1.8" 12.0-360.0mm F2.6 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity, Megapixel Rated

LMZ20750AMPDC-XF

1/1.8" 20.0-750.0mm F4.6 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity, Megapixel Rated


1/2" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, DC AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ0812AMPDC-IR

1/2" 8.0-120.0mm F1.8 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), IR, Megapixel

LMZ7527AMPDC

1/2" 7.5-127.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Megapixel

LMZ112AMPDC

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus)

LMZ123AMPDC

1/2" 12.0-300.0mm F1.8 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus)

LMZ375AMPDC-XF

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus w/ DC Auto-IrisC-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity

LMZ750AMPDC-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity

LMZ1000AMPDC-XF

1/2" 20.0-1000.0mm F3.5 Motorized Zoom & Focus w/ DC Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity


1/3" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, DC AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ111AMPDC

1/3" 6.0-60.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

LMZ110AMPDC

1/3" 6.0-90.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

LMZ200AMPDC

1/3" 5.6-112.0mm F1.6 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

LMZ300AMPDC

1/3" 5.5-165.0mm F1.8 Motorized Zoom & Focus w/ DC Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

MOTORIZED ZOOM | VIDEO AUTO IRIS

1/2" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ0812AMP-IR

1/2" 8.0-120.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), IR, Megapixel

LMZ7527AMP

1/2" 7.5-127.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Megapixel

LMZ112AMP

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus)

LMZ123AMP

1/2" 12.0-300.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus)

LMZ375AMP-XF

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity

LMZ750AMP-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity


1/3" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ111AMP

1/3" 6.0-60.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

LMZ110AMP

1/3" 6.0-90.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

LMZ200AMP

1/3" 5.6-112.0mm F1.6 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

LMZ300AMP

1/3" 5.5-165.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens, Presets (Zoom & Focus)

MOTORIZED ZOOM | VIDEO AUTO-IRIS W/ MANUAL OVERRIDE

1/2" FORMAT

MOTORIZED ZOOM & FOCUS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ112AMOR

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override

LMZ123AMOR

1/2" 12.0-300.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override

LMZ375AMOR-XF

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override, Extended IR Sensitivity

LMZ750AMOR-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override, Extended IR Sensitivity


1/3" FORMAT

MOTORIZED ZOOM & FOCUS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ300AMOR

1/3" 5.5-165mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens, Manual Iris Override

MOTORIZED ZOOM | VIDEO AUTO-IRIS W/ MANUAL OVERRIDE

1/2" FORMAT

MOTORIZED ZOOM & FOCUS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ112AMOR

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override

LMZ123AMOR

1/2" 12.0-300.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override

LMZ375AMOR-XF

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override, Extended IR Sensitivity

LMZ750AMOR-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Manual Iris Override, Extended IR Sensitivity


1/3" FORMAT

MOTORIZED ZOOM & FOCUS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ300AMOR

1/3" 5.5-165mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris CS-Mount Lens, Manual Iris Override

MOTORIZED ZOOM | VIDEO AUTO IRIS W/ MANUAL OVERRIDE

1/2" FORMAT

MOTORIZED ZOOM & FOCUS W/ PRESETS, VIDEO AUTO-IRIS

MODLE

DESCRIPTION

PDF

LMZ112AMPOR

1/2" 11.0-200.0mm F1.9 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Manual Iris Override

LMZ123AMPOR

1/2" 12.0-300.0mm F1.8 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Manual Iris Override

LMZ375AMPOR-XF

1/2" 15.0-375.0mm F2.3 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Manual Iris Override, Extended IR Sensitivity

LMZ750AMPOR-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens, Presets (Zoom & Focus), Manual Iris Override, Extended IR Sensitivity

MOTORIZED ZOOM | 3 MOTOR TYPE

1/1.8" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS

MODLE

DESCRIPTION

PDF

LMZ1236M3-XF

1/1.8" 12.0-360.0mm F2.6 Motorized Zoom, Focus & Iris C-Mount Lens, Extended IR Sensitivity, Megapixel


1/2" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS

MODLE

DESCRIPTION

PDF

LMZ375M3-XF

1/2" 15.0-375.0mm F2.3 Motorized Zoom, Focus & Iris C-Mount Lens, Extended IR Sensitivity

LMZ750M3-XF

1/2" 30.0-750.0mm F4.6 Motorized Zoom, Focus & Iris C-Mount Lens, Extended IR Sensitivity


1/3" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS

MODLE

DESCRIPTION

PDF

LMZ111M3R

1/3" 6.0-60.0mm F1.6 Motorized Zoom, Focus & Iris CS-Mount Lens

LMZ110M3R

1/3" 6.0-90.0mm F1.6 Motorized Zoom, Focus & Iris CS-Mount Lens

MOTORIZED ZOOM | 3 MOTOR W/ PRESETS

1" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS W/ PRESETS

MODLE

DESCRIPTION

PDF

LMZ16160M3P-IR

1" 16.0-160.0mm F1.9 Motorized Zoom, Focus & Iris C-Mount Lens, Presets (Zoom & Focus), IR Sensitivity, 5-Megapixel Rated

LMZ25300M3P-IR

1" 25.0-300.0mm F2.8 Motorized Zoom, Focus & Iris C-Mount Lens, Presets (Zoom & Focus), IR Sensitivity, 5-Megapixel Rated


2/3" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS W/ PRESETS

MODLE

DESCRIPTION

PDF

LMZ1177M3P-IR

2/3" 11.0-77.0mm F1.6 Motorized Zoom, Focus & Iris C-Mount Lens, Presets (Zoom & Focus), IR Corrected (Day/Night), 5-Megapixel Rated


1/1.8" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS W/ PRESETS

MODLE

DESCRIPTION

PDF

LMZ1236M3P-XF

1/1.8" 12.0-360.0mm F2.6 Motorized Zoom, Focus & Iris C-Mount Lens, Presets (Zoom & Focus), Extended IR Sensitivity, Megapixel


1/2" FORMAT

HDTV LENS, MOTORIZED ZOOM, FOCUS & IRIS W/ PRESETS

MODLE

DESCRIPTION

PDF

LMZ856-HD3

1/2" 8.0-56.0mm F1.2 Motorized Zoom, Focus & Iris C-Mount Lens, Presets (Zoom & Focus), 2 Megapixel HD Rated, For Close Focus Distance (0.7-3.0m Range), 3-CCD Type


1/2" FORMAT

MOTORIZED ZOOM, FOCUS & IRIS (3 MOTOR) W/ PRESETS

MODLE

DESCRIPTION

PDF

LMZ0812M3P-IR

1/2" 8.0-120.0mm F1.8 Motorized Zoom, Focus & Iris C-Mount Lens, Presets (Zoom & Focus), IR Corrected (Day/Night), Megapixel

ACCESSORIES

MODLE

DESCRIPTION

PDF

CS/C Adapter

5mm Adapter Ring (CS/C-Mount Adapter)
