HITACHI CAMERAS

Hitachi Kokusai Electric America, Ltd. is one of the world's leading suppliers of CCD cameras for industrial, video security, CCTV, and machine vision applications.

Product highlights include standard low-light and super low-light CCD cameras (down to 0.00003 lx), and high definition cameras (with IP & HD-SDI outputs) - with on-board processing features such as fog reduction.

Other products include industrial chassis cameras (in both HD and standard definition), 3-CCD color cameras (including HD remote head for medical applications), as well as a complete line of standard analog output models in both color and monochrome.


SURVEILLANCE SERIES

SURVEILLANCE

HIGH DEFINITION (NETWORK/IP & HD-SDI)

MODLE

DESCRIPTION

PDF

KP-HD2005R-S5

1/1.9" CMOS 2.4 Megapixel Full HD (1952 H x 1241 V) Color High Sensitivity HD Camera, Min. Illumination 0.009lx (color) and 0.0005lx (monochrome), Real-Time Fog Mitigation, HD-SDI & VBS Outputs, CS/C-Mount Adjustable

KP-HD2005R-S5-60X-Ruggedized

Hitachi Fully Integrated Camera/Zoom Lens System Installed in Housing includes KP-HD2005R-S5 Camera, 1/1.9", 16x9, 2.4 Megapixel CMOS Sensor, Fog, NIR Sensitive, IFPCB Board w/ Firmware, Power Board, Serial Control, Auto-Focus with Fujinon 60x 16.7-2000mm Zoom Lens w/ Day/Night/NIR, Spot Filter, Harness, Cables & Wiring, Reinforced Housing with HD Glass

KP-HD1005-S5

1/3" MOS-type 2.1 Megapixel HDTV Color Camera w/ Day/Night, 1080P 30/25, 1080i 60 Video Format, True 16 x 9 Aspect Ratio, HD-SDI Output, 0.2 lx Color (at F1.2), On-Board Fog/Smoke/Dust Cancellation Feature, Auto-Focus Signal, RS-232C/RS-485 Remote Control, C/CS-Mount, 12 VDC, Ruggedized

HV-HD33

1/3" 3-CMOS HDTV Color Camera, 1280H x 720V, 720 TVL, 1080i and 720p formats; HD-SDI, Component HD and analog RGB outputs, C-Mount

SURVEILLANCE SERIES

SURVEILLANCE

ANALOG OUTPUT (STANDARD DEFINITION)

MODLE

DESCRIPTION

PDF

KP-D5010-S2

1/2" CCD High Sensitivity DSP Color (NTSC) Camera, 768x494, Min. Illumination of 0.03 lux (color), 0.004 lux (B/W), 560 TVL (color), 580 TVL (B/W), RS-232 Control, Day/Night, Fog Cancellation Feature, 12VDC.

KP-D5010P-S2

1/2" CCD High Sensitivity DSP Color (PAL) Camera, 752x582, Min. Illumination of 0.03 lux (color), 0.004 lux (B/W), 560 TVL (color), 580 TVL (B/W), RS-232 Control, Day/Night, Fog Cancellation Feature, 12VDC.

KP-D5000-S1

1/2" CCD High Sensitivity DSP Color (NTSC) Camera, 768x494, Min. Illumination of 0.03 lux (color), 0.004 lux (B/W), 560 TVL (color), 580 TVL (B/W), RS-232 Control, Day/Night, Fog Cancellation Feature, 24 VAC/12 VDC switchable.

KP-D5001

1/2" CCD High Sensitivity DSP Color (NTSC) Camera, 768x494, Min. Illumination of 0.03 lux (color), 0.004 lux (B/W), 560 TVL (color), 580 TVL (B/W), RS-232 Control, Day/Night, Fog Cancellation Feature, 120 VAC.

KP-DE500

1/2" EM-CCD Super High Sensitivity Low-Light Color Camera w/ Day/Night, Thermoelectric Cooling, 480 TVL, 50 dB S/N, 0.0009 lx (color full motion at F1.2), 0.00005 lx (monochrome full motion at F1.2), 12 VDC.

KP-E500

1/2" EM-CCD Super High Sensitivity Low-Light Monochrome Camera, Thermoelectric Cooling, 480 TVL, 50 dB S/N, 0.0000008 lx (full motion at F1.2), 12 VDC.

HV-D30-S4

1/3" 3-CCD Compact Color Camera, NTSC, 768 H x 494 V, Composite/S-Video/RGB output, 800 TVL

HV-D30P-S4

1/3" 3-CCD Compact Color Camera, PAL, 752 H x 582 V, Composite/S-Video/RGB output, 800 TVL

AREA SCAN | INTERLACED CAMERAS

1/2" CCD

ANALOG OUTPUT (COLOR)

MODLE

DESCRIPTION

PDF

KP-D20BU

Compact Color DSP Camera, NTSC, 768 H x 494 V, RS-232C Control, CS-Mount, Composite & S-Video outputs

KP-D20BU PAK 1

Includes KP-D20BU camera, 45601-C1 power supply, TA-D20A tripod adapter, and CS/C-Mount adapter

KP-D20BP-S3

Compact Color DSP Camera, PAL, 752 H x 582 V, RS-232C Control, CS-Mount, Composite & S-Video outputs, Hirose 12-pin Connector

AREA SCAN | INTERLACED CAMERAS

1/3" CCD

ANALOG OUTPUT - COLOR

MODLE

DESCRIPTION

PDF

KP-D20AU

Compact CCD Color Camera, NTSC, 768 H x 494 V, 480 Lines, DSP, RS-232C, 12 VDC, S-Video and Composite Outputs

KP-D20AU PAK 1

Includes KP-D20AU camera, 45601-C1 power supply, TA-D20A tripod adapter, and CS/C-Mount adapter

KP-D20AP

Compact 1 CCD Color Camera, PAL, 752 H x 582 V, 470 Lines, DSP, RS-232C, 12 VDC

AREA SCAN | INTERLACED CAMERAS

1/3"

HIGH DEFINITION COLOR (HD-SDI)

MODLE

DESCRIPTION

PDF

KP-HD20A

1/3" 2.1-Megapixel Compact HDTV Color Camera, 1080P 30/25, 1080i 60 Video Format, True 16 x 9 Aspect Ratio, HD-SDI Output, RS-232C/RS-485 Remote Control, CS-Mount, 12 VDC

ACCESSORIES

CAMERA ACCESSORIES

MODLE

DESCRIPTION

PDF

45601-C1

12VDC Power Supply w/ Cable and 3-pin Connector for KP-FD30 Series, KP-D20BU, KP-D20BP, KP-D20AU, KP-D20AP, KP-HD20A, HV-D27A, HV-HD201M, HV-HD201, HV-D30-S4, HV-D30P-S4, and HV-HD33 Cameras

45601-C4

12VDC Power Supply w/ Cable and 12-pin Connector for KP-M1, KP-M2, KP-M3 Series, KP-F Series, HV-F22, and HV-F31 Cameras

45601-C5

12VDC Power Supply w/ Power Connector, H&V Drive Cables, Trigger Cable, and Video Output Cable, all with BNC Connectors (for KP-F Series Cameras)

45601-C9

12VDC Power Supply w/ 15' Cable and 12-pin Connector, and 15' Video Cable w/ BNC Connector for KP-F3, KP-M1, KP-M2, and KP-M3 Series Cameras

PC-12P

12-pin Power Connector for KP-M1, KP-M2, KP-M3 Series, KP-F Series, HV-F22, and HV-F31Cameras

DV12-C1

12VDC Power Supply for KP-DE500 & KPE500 Camera, 2.5A, 3-pin connector

C9DRGB

RGB Cable for HV Series Camera

C9D232C-6

6 ft. RS-232C Control Cable for KP-D5010, KPD5010P, KP-D20A, and KP-D20B

CSV20

20' Y/C Cable for KP-D & HV Series Cameras

TA-M1

Tripod Adapter for KP-M Series

TA-D20A

Tripod Adapter for KP-D20AU & KP-D20BU Cameras
