FUJINON LENSES

Fujinon, Inc. (FUJIFILM Corporation) offers a wide range of superior quality yet economically priced machine vision lenses - including 12 megapixel rated, newly designed 5 megapixel rated, and 3 megapixel rated - all compact in size and designed for current 2/3" size sensors.

Other products include standard machine vision fixed focal lenses, wide angle (fisheye type), megapixel rated vari-focals, and TF series designed for 3-CCD type cameras. Various mid-range and long-range "broadcast quality" motorized zoom lens models round out Fujinon's full lineup of industrial and security lenses.


FIXED FOCAL LENGTH | MANUAL IRIS

2/3" FORMAT

12 MEGAPIXEL RATED FOR MACHINE VISION

MODLE

DESCRIPTION

PDF

HF818-12M

2/3" 8mm F1.8 Manual Iris C-Mount Lens, 12 Megapixel Rated

HF1218-12M

2/3" 12mm F1.8 Manual Iris C-Mount Lens, 12 Megapixel Rated

HF1618-12M

2/3" 16mm F1.8 Manual Iris C-Mount Lens, 12 Megapixel Rated

HF2518-12M

2/3" 25mm F1.8 Manual Iris C-Mount Lens, 12 Megapixel Rated

HF3520-12M

2/3" 35mm F2.0 Manual Iris C-Mount Lens, 12 Megapixel Rated


2/3" FORMAT

5 MEGAPIXEL RATED FOR MACHINE VISION
(COMPACT DESIGN)

MODLE

DESCRIPTION

PDF

HF6XA-5M

2/3" 6mm F1.9 Manual Iris C-Mount Lens, Compact Size, Low Distortion, 5 Megapixel Rated (for 3.45 µm Pixel Pitch)

HF8XA-5M

2/3" 8mm F1.6 Manual Iris C-Mount Lens, Compact Size, Low Distortion, 5 Megapixel Rated (for 3.45 µm Pixel Pitch)

HF12XA-5M

2/3" 12mm F1.6 Manual Iris C-Mount Lens, Compact Size, Low Distortion, 5 Megapixel Rated (for 3.45 µm Pixel Pitch)

HF16XA-5M

2/3" 16mm F1.6 Manual Iris C-Mount Lens, Compact Size, Low Distortion, 5 Megapixel Rated (for 3.45 µm Pixel Pitch)

HF25XA-5M

2/3" 25mm F1.6 Manual Iris C-Mount Lens, Compact Size, Low Distortion, 5 Megapixel Rated (for 3.45 µm Pixel Pitch)

HF35XA-5M

2/3" 35mm F1.9 Manual Iris C-Mount Lens, Compact Size, Low Distortion, 5 Megapixel Rated (for 3.45 µm Pixel Pitch)


2/3" FORMAT

5 MEGAPIXEL RATED FOR MACHINE VISION

MODLE

DESCRIPTION

PDF

FE185C057HA-1

2/3" 1.8mm (Fisheye) F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, 185° fov

HF12.5SA-1

2/3" 12.5mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

HF16SA-1

2/3" 16mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

HF25SA-1

2/3" 25mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

HF35SA-1

2/3" 35mm F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated

HF50SA-1

2/3" 50mm F1.8 Manual Iris C-Mount Lens, 5 Megapixel Rated

HF75SA-1

2/3" 75mm F1.8 Manual Iris C-Mount Lens, 5 Megapixel Rated


2/3" FORMAT

3 MEGAPIXEL RATED FOR MACHINE VISION

MODLE

DESCRIPTION

PDF

HF8XA-1

2/3" 8mm F1.6 Manual Iris C-Mount Lens, 3 Megapixel Rated

HF12XA-1

Fujinon 2/3" 12mm F1.6 Manual Iris C-Mount Lens, 3 Megapixel Rated

HF16XA-1

2/3" 16mm F1.6 Manual Iris C-Mount Lens, 3 Megapixel Rated

HF25XA-1

2/3" 25mm F1.6 Manual Iris C-Mount Lens, 3 Megapixel Rated

HF35XA-1

2/3" 35mm F1.9 Manual Iris C-Mount Lens, 3 Megapixel Rated


1/2" FORMAT

1.5 & 5 MEGAPIXEL RATED FOR MACHINE VISION

MODLE

DESCRIPTION

PDF

FE185C046HA-1

1/2" 1.4mm (Fisheye) F1.4 Manual Iris C-Mount Lens, 5 Megapixel Rated, 185° fov

DF6HA-1B

1/2" 6mm F1.2 Manual Iris C-Mount Lens, 1.5 Megapixel Rated


2/3" FORMAT

1.5 MEGAPIXEL RATED FOR MACHINE VISION

MODLE

DESCRIPTION

PDF

HF9HA-1B

2/3" 9mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HF12.5HA-1B

2/3" 12.5mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HF16HA-1B

2/3" 16mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HF25HA-1B

2/3" 25mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HF35HA-1B

2/3" 35mm F1.6 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HF50HA-1B

2/3" 50mm F2.3 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HF75HA-1B

2/3" 75mm F2.8 Manual Iris C-Mount Lens, 1.5 Megapixel Rated


2/3" FORMAT

DAY/NIGHT FOR LONG RANGE SECURITY
(5 MEGAPIXEL RATED)

MODLE

DESCRIPTION

PDF

HF35SR4A-1

2/3" 35mm F2.0 Manual Iris C-Mount Lens, Day/Night, 5 Megapixel Rated

HF35SR4A-SA1L

2/3" 35mm F2.0 DC Auto Iris C-Mount Lens, Day/Night, 5 Megapixel Rated

HF50SR4A-1

2/3" 50mm F2.8 Manual Iris C-Mount Lens, Day/Night, 5 Megapixel Rated

HF50SR4A-SA1L

2/3" 50mm F2.8 DC Auto-Iris C-Mount Lens, Day/Night, 5 Megapixel Rated


1" FORMAT

1.5 & 5 MEGAPIXEL RATED FOR MACHINE VISION

MODLE

DESCRIPTION

PDF

FE185C086HA-1

1" 2.7mm (Fisheye) F1.8 Manual Iris C-Mount Lens, 5 Megapixel Rated, 185° fov

CF12.5HA-1

1" 12.5mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

CF16HA-1

1" 16mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

CF25HA-1

1" 25mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

CF35HA-1

1" 35mm F1.4 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

CF50HA-1

1" 50mm F1.8 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

CF75HA-1

1" 75mm F1.8 Manual Iris C-Mount Lens, 1.5 Megapixel Rated

HIGH DEFINITION LENSES | FIXED FOCAL & MOTORIZED ZOOM

1/3" FORMAT

4K ULTRA HD FOR 3-CCD/3-CMOS SENSOR CAMERAS

MODLE

DESCRIPTION

PDF

TF4XA-1

1/3" 4mm F2.2 Manual Focus & Iris C-Mount Lens for 3-CCD and 3-CMOS HD Camera, Full HD/Broadcast Quality, 4K Ultra HD

XT17sx4.5DA-R11

1/3" 4.7-77mm (17X) F1.6 Motorized Zoom & Focus w/ Video Auto-Iris C-Mount Lens for 3-CCD and 3-CMOS HD Camera, Presets, Servo Control, Full HD/Broadcast Quality, 4K Ultra HD

FIXED FOCAL LENGTH | MANUAL IRIS

1/3" FORMAT

FOR 3-CCD/3-CMOS SENSOR CAMERAS

MODLE

DESCRIPTION

PDF

TF2.8DA-8

1/3" 2.8mm F2.2 Manual Iris C-Mount Lens, 3-CCD Type

TF4DA-8

1/3" 4mm F2.2 Manual Iris C-Mount Lens, 3-CCD Type

TF8DA-8B

1/3" 8mm F2.2 Manual Iris C-Mount Lens, 3-CCD Type

TF15DA-8

1/3" 15mm F2.2 Manual Iris C-Mount Lens, 3-CCD Type

TF25DA-8B

1/3" 25mm F2.2 Manual Iris C-Mount Lens, 3-CCD Type

PANAMORPH | SPECIALTY LENS

1/2.5" FORMAT

360° VIEW, 5 MEGAPIXEL (HD) RATED LENS

MODLE

DESCRIPTION

PDF

DF360SR4A-SA2

1/2.5" 1.3mm F2.0 DC Auto-Iris CS-Mount Panamorph Lens - for 360° Angle of View, Day/Night, 5 Megapixel (HD) Rated

VARI-FOCAL LENGTH | VARI-FOCAL LENGTH

1/3" FORMAT

3 MEGAPIXEL RATED (HD)

MODLE

DESCRIPTION

PDF

YV2.7X2.2SA-2

1/3" 2.2-6mm F1.3 Manual Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated

YV2.8X2.8SA-2

1/3" 2.8-8mm F1.2 Manual Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated

YV4.3X2.8SA-2

1/3" 2.8-12mm F1.4 Manual Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated

YV3.3X15SA-2

1/3" 15-50mm F1.5 Manual Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated


1/3" FORMAT

FOR STANDARD RESOLUTION CAMERAS

MODLE

DESCRIPTION

PDF

YV2.2X1.4A-2

1/3" 1.4-3.1mm F1.4 Manual Iris Vari-Focal CS-Mount Lens

YV2.4x2.5A-2

1/3" 2.5-6mm F1.2 Manual Iris Vari-Focal CS-Mount Lens

YV2.8X2.8LA-2

1/3" 2.8-8mm F0.95 Manual Iris Vari-Focal CS-Mount Lens

YV10X5B-2

1/3" 5-50mm F1.3 Manual Iris Vari-Focal CS-Mount Lens


1/2" & 1/1.8"
FORMAT

3 & 5 MEGAPIXEL RATED (HD)

MODLE

DESCRIPTION

PDF

DV3.4X3.8SA-1

1/2" 3.8-13mm F1.4 Manual Iris Vari-Focal C-Mount Lens, 3 Megapixel Rated

DV3.8X4SR4A-1

1/1.8" 4-15.2mm F1.5 Manual Iris Vari-Focal C-Mount Lens, 3 Megapixel Rated, Day/Night

DV4X12.5SR4A-1

1/1.8" 12.5-50mm F1.6 Manual Iris Vari-Focal C-Mount Lens, 5 Megapixel Rated, Day/Night

DV10X8SR4A-1

1/2" 8-80mm F1.6 Manual Iris Vari-Focal C-Mount, 3 Megapixel Rated, Day/Night

VARI-FOCAL LENGTH | DC AUTO-IRIS

1/3" FORMAT

3 MEGAPIXEL RATED (HD)

MODLE

DESCRIPTION

PDF

YV2.7X2.2SA-SA2

1/3" 2.2-6mm F1.3 DC Auto-Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated

YV2.1X2.8SR4A-SA2

1/3" 2.8-6mm F1.3 DC Auto-Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated, Day/Night

YV2.8X2.8SA-SA2

1/3" 2.8-8mm F1.2 DC Auto-Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated

YV4.3X2.8SA-SA2

1/3" 2.8-12mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated

YV3.3X15SA-SA2

1/3" 15-50mm F1.5 DC Auto-Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated (Covers 1/2.7" Sensor)

YV3.3X15SR4A-SA2

1/3" 15-50mm F1.5 DC Auto-Iris Vari-Focal CS-Mount Lens, 3 Megapixel Rated, Day/Night (Covers 1/2.7" Sensor)


1/3" FORMAT

FOR STANDARD RESOLUTION CAMERAS

MODLE

DESCRIPTION

PDF

YV2.2X1.4A-SA2L

1/3" 1.4-3.1mm F1.4 DC Auto-Iris Vari-Focal CS-Mount Lens

YV2.4x2.5A-SA2L

1/3" 2.5-6mm F1.2 DC Auto-Iris Vari-Focal CS-Mount Lens

YV2.8X2.8LA-SA2L

1/3" 2.8-8mm F0.95 DC Auto-Iris Vari-Focal CS-Mount Lens

YV5X2.7R4B-SA2L

1/3" 2.7-13.5mm F1.3 DC Auto-Iris Vari-Focal CS-Mount Lens, Day/Night

YV10X5B-SA2L

1/3" 5-50mm F1.3 DC Auto-Iris Vari-Focal CS-Mount Lens


1/2" & 1/1.8"
FORMAT

3, 5 & 6 MEGAPIXEL RATED (HD)

MODLE

DESCRIPTION

PDF

DV3.4X3.8SA-SA1

1/2" 3.8-13mm F1.4 DC Auto-Iris Vari-Focal C-Mount Lens, 3 Megapixel Rated

DV3.8X4SR4A-SA1

1/1.8" 4-15.2mm F1.5 DC Auto-Iris Vari-Focal C-Mount Lens, 3 Megapixel Rated, Day/Night

DV4X12.5SA4A-SA1

1/1.8" 12.5-50mm F1.6 DC Auto-Iris Vari-Focal C-Mount Lens, 5 Megapixel Rated, Day/Night

DV10X8SA-SA1L

1/2" 8-80mm F1.4 DC Auto-Iris Vari-Focal C-Mount Lens, 3 Megapixel Rated

DV10X8SR4A-SA1L

1/2" 8-80mm F1.6 DC Auto-Iris Vari-Focal C-Mount Lens, 3 Megapixel Rated, Day/Night

DV2.2X4.1SR4A-SA2L

1/1.8" 4.1-9mm F1.6 DC Auto-Iris Vari-Focal CS-Mount Lens, 6 Megapixel Rated, Day/Night

MOTORIZED ZOOM | 2/3" 32X LENS (MID-RANGE)

2/3" FORMAT

2 MEGAPIXEL RATED (FULL HD)

MODLE

DESCRIPTION

PDF

FH32x15.6SR4A-CV1

2/3" 15.6-500mm (32x) F3.9 Motorized Zoom & Focus with Auto-Iris (DC/Video Type Switchable) C-Mount Lens with Analog, RS-232 & Pelco D Control, Day/Night, 2 Megapixel Rated (Full HD)

MOTORIZED ZOOM | 1/1.8" 32X LENS (MID-RANGE)

1/1.8" FORMAT

2 MEGAPIXEL RATED (FULL HD)

MODLE

DESCRIPTION

PDF

FD32x12.5SR4A-CV1

1/1.8" 12.5-400mm (32x) F3.1 Motorized Zoom & Focus with Auto-Iris (DC/Video Type Switchable) C-Mount Lens with Analog, RS-232 & Pelco D Control, Day/Night, 2 Megapixel Rated (Full HD)

MOTORIZED ZOOM | 1/1.8" 60X LENS (LONG-RANGE)

1/1.8" FORMAT

2 MEGAPIXEL RATED (FULL HD)

MODLE

DESCRIPTION

PDF

D60X16.7SR4DE-V21

1/1.8" 16.7-1000mm (33.4-2000mm w/ Electronic 2X) F3.5 Motorized Zoom & Focus w/ DC or Video Auto-Iris C-Mount Lens, Manual Override, Presets, Day/Night, Analog Control, 2 Megapixel Rated (Full HD)

D60X16.7SR4DE-V23S

1/1.8" 16.7-1000mm (33.4-2000mm w/ Electronic 2X) F3.5 Motorized Zoom & Focus w/ DC or Video Auto-Iris C-Mount Lens, Manual Override, Presets, Day/Night, Analog Control, 2 Megapixel Rated (Full HD), Optical Adjustment, Strengthened Body

D60X16.7SR4DE-ZP1A

1/1.8" 16.7-1000mm (33.4-2000mm w/ Electronic 2X) F3.5 Motorized Zoom & Focus w/ DC or Video Auto-Iris C-Mount Lens, Manual Override, Presets, Day/Night, Focus Assist (Auto-Focus), Servo & RS-232 Control, 2 Megapixel Rated (Full HD)

D60X16.7SR4FE-ZP1C

1/1.8" 16.7-1000mm (33.4-2000mm w/ Electronic 2X) F3.5 Motorized Zoom & Focus w/ DC or Video Auto-Iris C-Mount Lens, Manual Override, Presets, Day/Night, Focus Assist (Auto-Focus), Servo & RS-232 Control, 2 Megapixel Rated (HD), Optical Stabilization

MOTORIZED ZOOM | 1/2" 60X (LONG-RANGE)

1/2" FORMAT

ANALOG & RS-232 CONTROL

MODLE

DESCRIPTION

PDF

D60X12.5R3DE-V41

1/2" 12.5-750mm (25-1500mm w/ Electronic 2X) F3.8 Motorized Zoom and Focus w/ Video Auto-Iris C-Mount Lens, Manual Override, Presets, Day/Night, Analog Control

D60X12.5R3DE-ZP1

1/2" 12.5-750mm (25-1500mm w/ Electronic 2X) F3.8 Motorized Zoom and Focus w/ Video Auto-Iris C-Mount Lens, Manual Override, Presets, Day/Night, RS-232 Control

ACCESSORIES

RANGE EXTENDERS FOR C-MOUNT

MODLE

DESCRIPTION

PDF

HE20-1

2.0X Range Extender for C-Mount Lens

HE15-1

1.5X Range Extender for C-Mount Lens
